NEC LCD Technologies' High Luminance 21.3-Inch UXGA LCDs Suitable for Medical Use
For immediate use April 15, 2005
NEC LCD Technologies, Ltd.
21.3-Inch UXGA LCD for Medical Use
Model No.: NL160120AM27-06/06A & NL160120AC27-05
Tokyo, April 15, 2005 ---NEC LCD Technologies, Ltd. today announced that sample shipments of 2 kinds of its new 21.3-inch (54cm diagonal), ultra-extended graphic array (UXGA), amorphous silicon thin-film-transistor liquid crystal displays ("TFT LCDs"), part numbers "NL160120AC27-05" and "NL160120AM27-06/06A", will commence at the end of April 2005. These models are particularly suited to use in the medical field.
The main characteristics of the new models are as follows:
- NL160120AC27-05
- A. High Luminance
The combination of NEC LCD Technologies' own unique super-advanced, super-fine TFT ("SA-SFT") technology, and a high-intensity, direct, back-light system achieve a brightness of 450cd/m2, the highest brightness level in the UXGA and above class of color TFT LCDs. This color LCD module boasts enough brightness to be utilized for radiogram interpretation and can be used for a combination of purposes including image diagnosis requiring high-brightness and smooth grey-scale, and viewing of picture archiving and communication systems ("PACS") that require use of a color screen in order to display various images from a range of medical tests and instruments such as endoscopes, ophthalmoscopy, and ultrasound equipment. - B. High Color Separation
This module is equipped with a switchable 10-bit internal look-up-table ("LUT"), which makes it possible to customize gray-scale setting, enabling selection of the most suitable 16.77 million colors out of 1.06 billion. - C. Wide Viewing Angle
SA-SFT technology, which is based on an in-plane switching ("IPS") mode, fulfills the vital prerequisites of medical image diagnosis on LCD monitors by enabling an ultra-wide viewing angle of 170 degrees (contrast ratio greater than 10:1) and reducing the color and/or contrast shift problem that occurs due to a change in viewing angle. It also allows stable color display with little, if any, influence on viewing angle difference for multi-screen use. - NL160120AM27-06/06A
- A. High Luminance
The combination of NEC LCD Technologies' own unique super-advanced, super-fine TFT ("SA-SFT") technology, and a high-intensity, direct, back-light system achieve a brightness of 1800cd/m2, the highest brightness level in the UXGA and above monochrome class. This brightness level is exceeded in the case of image diagnosis with X-ray film on a light box. In addition, if the level of brightness is suppressed, stable brightness levels can be preserved over a long period of time. - B. High Grade Grey-Scale Performance
Each pixel consists of three sub-pixels, and each sub-pixel controls 256 grey-scales individually. In addition, the LCD module is equipped with a switchable 10-bit internal LUT, which makes it possible to customize gray-scale setting. This model thus enables selection of the most suitable 766 grey-scales per pixel out of 3,061 grey-scales, and also achieves smooth adjustment of gamma characteristics. - C. Wide Viewing Angle
SA-SFT technology, which is based on an in-plane switching ("IPS") mode, fulfills the vital prerequisites of medical image diagnosis on LCD monitors by enabling an ultra-wide viewing angle of 170 degrees (contrast ratio greater than 10:1) and reducing the gamma shift problem that occurs due to a change in viewing angle. It also allows stable color display with little, if any, influence on viewing angle difference for multi-screen use.
Recently, the use of LCD devices in the medical field has spread rapidly. Our LCD modules equipped with our proprietary SFT technology, which enables reproduction of high quality images and an ultra-wide viewing angle, are enjoying high acclaim in the medical field having been adopted widely by many medical equipment manufacturers worldwide.
NEC LCD Technologies has responded to these needs by expanding its line-up of monochrome and color LCDs, and will continue to develop advanced technologies to meet the greater and more sophisticated needs of its customers in a variety of fields worldwide.
*Please see the attached sheet for the main specifications of the new models.
