NEC LCD Technologies’ New High Luminance 21.3-Inch
Monochrome UXGA LCD Module for Medical Use
For immediate use September 29, 2006
NEC LCD Technologies, Ltd.
Tokyo, September 29, 2006 --- NEC LCD Technologies, Ltd. today announced that it will begin shipping samples of its new 21.3-inch (54-centimeters-diagonal) monochrome ultra extended graphics array (UXGA), amorphous silicon, thin film transistor liquid crystal display (TFT LCD) module, part number NL160120AM27-13A, at the end of October. The new LCD module is extremely suitable for medical use including diagnosis of radiogram interpretation of X-ray images. This new LCD, an upgraded model of NL160120AM27-06A launched in April 2005, boasts the highest luminance level in the UXGA and above monochrome class at 1700cd/m2 due to a combination of NEC LCD Technologies' own unique super-advanced, super-fine TFT (SA-SFT) technology and a high-intensity, direct back-light system. Furthermore, the new product realizes high contrast performance and brightness uniformity as a result of innovative modification of the LCD panel design.
The main characteristics of the new model are as follows:
- High Luminance
The combination of NEC LCD Technologies' own unique super-advanced, super-fine TFT (SA-SFT) technology and a high-intensity, direct back-light system achieve a luminance of 1700cd/m2, the highest luminance level in the UXGA and above monochrome class. This brightness level is exceeded in the case of image diagnosis with X-ray film on a light box. In addition, if the level of luminance is suppressed, stable luminance levels can be preserved over a long period of time. - High Contrast Performance
A review in panel design has achieved a reduction in the level of black brightness by at least 30% as compared with the conventional model, NL160120AM27-06A, although both are equipped with a high-intensity, direct back-light system. As a result, a high contrast ratio of 850:1, the highest ratio in the UXGA and above monochrome class, is realized. In addition, optimization of the optical design inhibits a "washed-out black" phenomenon that occurs when the viewing angle is enlarged - currently a common issue with in-plane switching (IPS) type LCD modules - leading to enhanced viewing angle performance of the contrast ratio. - High Brightness Uniformity
A review in the panel design and optical design has reduced the brightness difference of the screen, realizing high brightness uniformity of the entire screen, a feature that has long-been sought after in medical image diagnosis.
NEC LCD Technologies has continuously focused on R&D pursuing better picture quality based on its proprietary SFT technology in response to the advanced needs of a wide variety of professional fields, including the medical field. "We are confident that our new 21.3-inch monochrome LCD will fulfill the current needs of the medical market. It not only tops its class in terms of high luminance and color contrast, but answers demands for UXGA LCDs for image diagnosis that can maintain high brightness uniformity over long periods of time," said Hidetoshi Usui, department manager in charge of product planning and marketing, NEC LCD Technologies, Ltd. "At NEC LCD Technologies we aim to leverage our years of technological know-how to synergize excellent picture quality with adaptive design technologies, bringing the best product to market every time."
NEC LCD Technologies will continue to pursue an even higher level of picture quality to supply products unrivaled in the medical field. This new product will be displayed at FPD International 2006, which is being held in Pacifico Yokohama, Japan, from October 18 - 20.
*Please see the attachment for the main specifications of the new 21.3-inch LCD.
21.3-Inch TFT LCD" NL160120AM27-13A"
